| DS-1500W 控制器 (GCI-1500) |
| Nominal Power： |
1.5KVA |
| Max. DC Power： |
PDC, max. = 1600W |
| Max. DC voltage： |
VDC, max. 450 V DC |
| Nominal DC range： |
VDC 70 V - 400 V DC |
| Efficiency： |
ηmax> 94 % |
| Europe Efficiency： |
ηeuro> 92 % |
| Max. input current： |
IDc, max. 10 A DC |
| Voltage ripple： |
VPP < 10% |
| Pole confusion protection： |
Fuse |
| Nominal AC Output Power： |
1400W AC |
| Max. AC Output Power： |
31500W AC |
| Operating Range Utility Voltage： |
200 – 260 V AC |
| Operating Range Utility Voltage： |
200 – 260 V AC |
| Operating range utility frequency： |
49– 50.3 Hz |
| Total Harmonic Distortion (THD)： |
THDIAC < 5 % |
| Power Factor： |
> 0.98 |
| Utility Monitoring： |
VAC; fAC Islanding protection VAC; fAC in accordance with ER G83/1, UL 1741,IEEE929 |
| Short Circuit Protection： |
Current controlled, Fuse |
| External Interfaces： |
Screw Terminal Block
Data transmission via electrically isolated RS485 |
| Internal consumption during operation： |
< 15 W |
| Internal Consumption During Stand-By： |
< 15W |
| Night Time Consumption： |
< 15 W |
| Operation Surroundings Temperature： |
－10℃～＋40℃ |
| Operation Surroundings Humidity： |
0～90% |
| Dimensions (HxWxD)： |
483x267x124mm |
| Weight： |
13 Kgs |
| Waterproof： |
IP42 |
| Certification： |
CE |
| (以上数据及规格如有变更，恕不另行通知!) |
| 有关更多GCI-1500的详细资料，请访问Ginlong网站。 |
|
|
|
